C.K.R Connecting Rod for Yamaha RX125, RXK, DT125, DT175

Product Application

This high-performance C.K.R connecting rod is specifically engineered for Yamaha RX125, RXK, DT125, and DT175 models, ensuring exceptional durability and compatibility with these popular motorcycles. Designed to meet the exacting standards of Yamaha's original equipment, this connecting rod offers reliable performance and a perfect fit.

Specifications

• Big-end Width: 16 mm
• Small-end Width: 16 mm
• Big-end Bore: 28 mm
• Small-end Bore: 20 mm
• Center-to-center Length: 100 mm
• Pin Diameter: 22 mm
• Pin Length: 54.5 mm
• Big-end Bearing Size: 22 x 28 x 16 mm
• Small-end Bearing Size: 16 x 20 x 20 mm
• Washer Thickness: 1.0 mm

Compatibility

This C.K.R connecting rod is compatible with the following Yamaha models:

• Yamaha RX125
• Yamaha RXK
• Yamaha DT125
• Yamaha DT175

Product Code

OE Number: 4Y2-11651-00
