For Honda H-100S

For Honda H-100S

Application:
Honda H-100S
Model : 168

Application:

Honda H-100S



Big-end Width (mm): 14

Small-end Width (mm): 14

Big-end Bore (mm): 26

Small-end Bore (mm): 19

Center-to-center (mm): 100

Pin Diameter (mm): 20

Pin Length (mm): 48

Big-end Bearing (mm): 20*26*14

Small-end Bearing (mm): 14*19*17

Washer Thickness (mm): 1.0
